Stainless Steel 316L Flanges are high-quality, low-carbon flanges made from SS 316L stainless steel, which provides excellent corrosion resistance, strength, and durability. These flanges are ideal for applications requiring high resistance to pitting, crevice corrosion, and extreme temperatures.
SS 316L is a low-carbon variant of SS 316, making it suitable for welding applications and reducing the risk of carbide precipitation. This enhances its usage in marine, chemical, food processing, oil & gas, and pharmaceutical industries.
Order Now
Stainless Steel 316L Flanges are known for their high corrosion resistance, durability, and superior strength. With a low carbon composition, these flanges minimize the risk of carbide precipitation, making them ideal for welding applications. Industries such as oil & gas, chemical processing, marine, and pharmaceuticals rely on SS 316L flanges due to their resistance to harsh environments, extreme temperatures, and pressure variations.
.jpeg)
Stainless Steel 316L flanges come in a variety of designs, each serving a unique purpose in industrial piping systems. These flanges ensure secure connections, efficient fluid flow, and leak-proof operations in high-performance environments. Below are the key types of SS 316L flanges and their functions:
SS 316L flanges provide excellent resistance against chloride-rich, acidic, and saline environments, making them perfect for marine and chemical industries.
With a high tensile and yield strength, Stainless Steel 316L Flanges can withstand extreme temperature and pressure conditions without deformation.
The low carbon content in SS 316L prevents carbide precipitation, making it ideal for welding applications.
SS 316L flanges require low maintenance and offer long service life.
India is home to leading SS 316L flange manufacturers offering precision-engineered flanges meeting ASTM, ASME, ANSI, DIN, and EN standards.
With various types of flanges available, selecting the right SS 316L flange depends on application-specific requirements. Understanding these options ensures optimal performance and cost-effective solutions.
| Specification | Details |
|---|---|
| Material Grade | Stainless Steel 316L (Low Carbon Austenitic) |
| Standard | ASTM A182 / ASME SA182 |
| Size Range | ½” to 48” (DN15 to DN1200) |
| Pressure Ratings | 150#, 300#, 600#, 900#, 1500#, 2500# |
| Face Type | RF, FF, RTJ |
| Types | Slip-On, Weld Neck, Blind, Threaded, Socket Weld, Lap Joint, Orifice, Expander, Reducing |
| Connection Type | Bolted, Welded, Threaded |
| Temperature Resistance | Suitable for high & low temperature applications |
| Corrosion Resistance | Superior resistance to oxidation, pitting, and crevice corrosion |
| Element | Composition (%) |
|---|---|
| Carbon (C) | 0.03 max |
| Manganese (Mn) | 2.00 max |
| Phosphorus (P) | 0.045 max |
| Sulfur (S) | 0.030 max |
| Silicon (Si) | 1.00 max |
| Chromium (Cr) | 16.0 – 18.0 |
| Nickel (Ni) | 10.0 – 14.0 |
| Molybdenum (Mo) | 2.00 – 3.00 |
| Nitrogen (N) | 0.10 max |
| Property | Value |
|---|---|
| Tensile Strength | 485 MPa (min) |
| Yield Strength | 170 MPa (min) |
| Elongation | 40% (min) |
| Hardness (Brinell) | 217 max |
| Hardness (Rockwell B) | 95 max |
| Region | Countries |
|---|---|
| Middle East | Saudi Arabia, Iran, Iraq, UAE, Qatar, Bahrain, Oman, Kuwait, Turkey, Yemen, Syria, Israel, Jordan, Cyprus |
| Asia | Singapore, Malaysia, Indonesia, Thailand, Vietnam, South Korea, Japan, Sri Lanka, Maldives, Bangladesh, Myanmar, Taiwan, Cambodia |
| South America | Argentina, Bolivia, Brazil, Chile, Venezuela, Colombia, Ecuador, Guyana, Paraguay, Uruguay |
| North America | USA, Canada, Mexico, Panama, Costa Rica, Puerto Rico, Trinidad and Tobago, Jamaica, Bahamas |
| Europe | Denmark, Russia, Norway, Germany, France, Italy, UK, Spain, Ukraine, Netherlands, Belgium, Greece, Czech Republic, Portugal, Hungary, Albania, Austria, Switzerland, Slovakia, Finland, Ireland, Croatia, Slovenia, Malta |
| Africa | Nigeria, Algeria, Angola, South Africa, Libya, Egypt, Sudan, Equatorial Guinea, Republic of Congo, Gabon |
| Continental Supply | Europe, Africa, Asia, North America, South America, Middle East, Far East |
| State | Major Cities |
|---|---|
| Andhra Pradesh | Vishakhapatnam, Vijayawada |
| Gujarat | Ahmedabad, Surat, Rajkot, Vadodara |
| Karnataka | Bengaluru |
| Kerala | Cochin |
| Maharashtra | Mumbai, Navi Mumbai, Pune, Nashik, Nagpur, Solapur, Kolhapur, Ambernath, Ahmednagar, Latur |
| Tamil Nadu | Chennai |
| Telangana | Hyderabad |
| Uttar Pradesh | Kanpur, Ghaziabad, Noida |
| West Bengal | Kolkata, Durgapur |
| Union Territories | Delhi, New Delhi, Chandigarh |
If you are looking for top-quality Stainless Steel 316L Flanges, we offer a wide range of SS 316L flanges that ensure durability, strength, and corrosion resistance. Contact us today for competitive prices and bulk orders!
